Uni Pavers by Chelsea Concrete

Pavers

Uni Pavers

Interlocking zig-zag for heavy loads

The wavy interlocking profile spreads load to neighbouring blocks, which is why it is the go-to for industrial yards, petrol pumps and roads.

Specifications

Category
Pavers
Thickness / size
80 mm / 100 mm / 120 mm
Finish
Plain grey or colour
Standard
IS 15658:2006
Strength grade
M-30 to M-50, selected by traffic category
Quality control
25 checks per batch, test report on request
Packing & delivery
Shrink-wrapped pallets, crane-unloaded at site
Manufactured at
IMT Bawal, Haryana (own plant)

Delivered on our own crane-mounted trucks, 96%+ on time, unloaded at site with no labour needed. Supplier profile

Best for

  • Industrial yards
  • Petrol pumps
  • Warehouses
  • Internal roads

Expert tip from our site team

Interlock only works when joints are full. After laying, sweep in dry fine sand and plate-compact twice — empty joints are the #1 reason uni pavers rock.

Enquire about Uni Pavers on WhatsApp(opens WhatsApp)

Pricing, colours and delivery — usually answered same day.

Technical drawing

Uni Pavers dimensional layout

Laying pattern, unit plan views and cross-section for site planning and quantity take-offs. Manufactured to IS 15658:2006.

Uni paver dimensional layout: interlocking laying pattern of 10 rows by 4 columns, 220x110 mm plan view, 8 mm joints, and 60, 80 and 100 mm cross-sections(opens full-size drawing in a new tab)
All dimensions in millimetres. Click the drawing to view full size.

Key dimensions

Size
220 × 110 mm
Thickness
60 / 80 / 100 mm
Joint
8 mm (depth 5–10 mm)
Pallet quantity
10 rows × 4 columns = 40 pavers
Colour
Grey

Before you buy, read this

Similar products

Grass Pavers by Chelsea ConcretePavers

Grass Pavers

Green parking that actually carries a car

Expert tip: Fill cells with a sandy topsoil mix and keep it 5–10 mm below the concrete rib. Overfilled cells get crushed by tyres and the grass dies within a season.

Thickness
80 mm / 100 mm
Finish
Natural grey
Aman® by Chelsea ConcretePavers

Aman®

Rustic stone character in a sunset blend

Expert tip: Mix units from at least three pallets as you lay. Blended colours are designed to be shuffled — laying one pallet at a time creates visible patches.

Dimensional layout
Aman paver dimensional layout: one pallet of mixed rustic units covering 1.14 square metres, with an 80 mm cross-section and 5 to 10 mm joint depth
Thickness
60 mm / 80 mm
Finish
Rustic textured, colour-blended
Amara® by Chelsea ConcretePavers

Amara®

Roman mosaic for artistic layouts

Expert tip: Set out the centre point and string lines before laying a single block. Mosaic patterns forgive nothing — a 5 mm error at the centre becomes 50 mm at the edge.

Dimensional layout
Amara® pallet layout showing unit sizes and arrangement
Thickness
60 mm / 80 mm
Finish
Smooth, multi-tone
